Cubicle Safety Shower

MODEL: CS1R
CATEGORY: Mains-Fed
STANDARDS:
ANSI Z358.1-2014, EN15154
SUITABLE FOR:
Indoor, Outdoor, Hazardous/Non-Hazardous Areas

KEY BENEFITS:
• Long-Lasting: Built from CORROSION RESISTANT materials
• Water contained within shower
• Highly visible, comes with photo-luminous signage

Need more information?

Description

Mains-fed Safety Shower with GRP cubicle and stainless steel framework

  • This unit meets and exceeds ANSI and EN standards
  • The shower and cubicle are built from robust, corrosion resistant materials for a long and trouble-free life
  • Neatly contains the water released from the shower in a drain sump
  • Illuminated signs mean the shower can be quickly located, even in low light conditions
  • The shower comes with a testing lever for easy inspection
  • Optional eye washes can be installed internally or externally
  • Many optional extras are also available to suit your requirements including different types of flooring and curtains, visual and audible alarms as well as valve arrangements to allow connection to the mains water supply.

This cubicle safety shower is suitable for all climates and fully compliant with ANSI Z358.1-2014 and EN15154 standards. A cubicle shower is designed to contain any water spray generated when it is in use. The unit is completely corrosion resistant and suitable for hazardous or non-hazardous environments. Comes with panelling and drain sump as standard. Available in two sizes regular and large.

For the large model please see MODEL CS1L
For temperatures below -25°C please see MODEL CS1A

Technical Details

RECOMMENDED WATER SUPPLY PRESSURE 2-3 bar
TEMPERATURE -5°C to +50°C (for temperatures below -5°C, please add optional frost protection)
DIMENSIONS
2.74 x 1.0 x 0.92 (m)
INLET CONNECTION 1” Stainless BSPM
SHOWER DRAIN OUTLET CONNECTION 2” Stainless BSPF (flanged options available)
SHOWER FLOW RATE 76lpm
SHOWER OPERATION Stainless panic bar + GRP walk-on platform
SIGNAGE Self-adhesive photo-luminous pictorial sign
EYE WASH FLOW RATE (if fitted) 23lpm
EYE WASH OPERATION (if fitted) Lift lid (foot operation as option)
STAINLESS EYE WASH OPERATION (if fitted) Hand lever
